Wiro Binding Machine

Leading Manufacturers, Exporters, Wholesaler, Trader and Importer of Automatic wiro binding machine WD60A (3:1), Semi-Automatic Paper Punching Binding Machine 430 Mm Width Die Changeable 150 Punches/Min and Wiro+Comb Binding Machine| 2016 from Delhi.

Business Type Manufacturer, Exporter, Supplier, Trader
Type Book Binding Machine
Material Mild Steel
Brand Name Namibind
Certification ISO 9001:2008 Certified
Color White
Packaging Type Wooden Box
Feature Rust Proof, Long Life, High Performance, Easy To Operate
Weight 31.8 Kg
Max. Punching Capacity 25 Sheets
Max. Punching Width Below 340 mm (F4)
Max. Binding Capacity 300 Sheets
Punching Speed 1.5 Sec/Time
Number of Hole 27 (2:1) or 40 (3:1)
Power Supply 110/240V, 50/60Hz 120W
Adjustable margin 2.5-6.5
Quantity of Movable Cutter All
Size 43 x 45 x 20 cm
Max Production Length 420mm
Max Production Thickness 460-60mm
Power Source /Power 220V 50Hz
Power Consumption 1.6/1.5KW/h
Mechanical Operation Speed 400/280
Size /Volume 1400×650×1100mm
Milling Cutter Way Double-Decked 24 Measure Only The Milling Cutter/Sun Knife
Net Weight 220/210/200Kg
Port courier
Delivery Time 6-7 days
Packaging Details wooden box packing

Click to view more

Namibind's wiro binding machine is a perfect machine for making books, notebooks, registers, calendars, books and many documents for printing industries. this machine is ideal for book publishers, printing industries, educational institutes, and many more. Namibind is a manufacturer of all types of book-binding machines, such as wiro binding machines, and spiral binding machines.

Read More...

Request to Call


Business Type Manufacturer, Exporter, Trader
Brand Name Namibind
Material Stainless Steel
Finishing Polished
Driven Type Electric
Color Brown,Yellow & Red
Condition New
Power 1-3kw
Pressure High Pressure
Operating Type Semi Automatic
Usage Book Binding
Certification ISO 9001:2008 Certified
Voltage 220V
Packaging Type Wooden Box
Phase Single Phase
Warranty 1 Year
After-Sales Service Provided door step services
Country of Origin India
Machine Structure Vertical
Model Super ZX450
Machine Type Combo/Punching Binding Machine | Die Changeable
Max. Punching Width 430 mm
Max. Punching Thickness Capacity 4 Mm 40 Paper At a Time
Punching Speed 150 Times/min
Gross Weight of Machine 260 kg Approx.
Punching Die Size 17”
Punching Die Available Wiro 3:1, Wiro 2:1, Calendar D cut, Spiral, Comb
Extra Die Weight 8 Kg
Port courier
Delivery Time 6-7 days
Packaging Details wooden box packing

Click to view more

Namibind ZX-450 is a heavy-duty electric multi-paper punching & wiro binding machine, which can be used in industry, enterprise, and large organizations with the firm design. With a handsome and commodious appearance. The motor can run continuously and punching/ binding is controlled by a foot pedal which is easy and safe for hand-free operation. ZX-450 Has advanced technology motor reducer and special-made mechanical clutch.

  • Interchangeable punching multi-die is easy and fast change, which can punch various Holes. Closing double wiro is also available by changing punching dies into the closing die and can close any size of double wiro wire.
  • The working fron
  • With wire closing system for both 3:1&2:1 on the back of the  paper punching machine
  • Can closer wiro from 4.8mm to 38mm(3/16” to 11/2”) & size maximum 17″
  • Easy operation by foot pedal system Exchangeable paper punching dies for all kinds of punching patterns.
  • Punching margin is adjustable from 2.5mm to 6.5mm (not include the calendar dies)
  • With wire closing system for both 3:1 & 2:1 on the back of the machine
  • Can closer wire from 4.8 mm to 38 mm(3/16” to 11/2”)
  • Easy operation by foot pedal
  • Exchangeable punching dies for all kinds of punching pattern
  • Change dies is easy and fast, take 5/10 minutes.
  • Multiple Punching Die Available
  • Close of Double wire is easy



2 in 1 Punch and Double Wire Binding floor type binding  Machine. Very easy to use with electric binding & punching machine in the back. Interchangeable dies can be changed within 10 minutes!

Read More...

Request to Call


34,000.00 / Piece

2 Piece (MOQ)

Get Best Price
Business Type Manufacturer, Exporter, Supplier, Trader
Max Punching (70-80g Sheet) 20 Sheets
Max Binding (70-80g sheet) 500 (4.8mm -51mm comb ring), 120 (4.8mm -14.3mm wire ring)
Suitable Paper Size F4 /A4 / B5/ Letter / A5
Paper Margin (mm) 2.5 / 4.5 / 6.5
Hole Quantity (pc) 24 comb / 40 wire
Hole Distance 14.3 comb / 8.47 wire P3:1
Weight 27 Kgs
Brand Name Namibind
Port courier
Delivery Time 6-7 days
Packaging Details wooden box packing

Click to view more

Wiro Binding Machine is used for numbers of paper together with card bored hard paper to make the cover of the book. Wiro binder machine also called wire binder machine as making wire Binder use metal wire to bind papers. Wiro binder is used for strong bind. It comes in different sizes according to the number of papers and length of the binding material.



Wiro document Binding Solution

Twin Loop wiro binding is one of the most popular binding methods of bookbinding available in the Indian binding segment today, Indian diary & calendar segment completely used in wiro ring wire, Twin Loop wiro binding is also known as double-loop metal wire binding available spool drum reel-type box packing & A4 size cut pice standard box single pice separate packing, wiro colour coatings are paint coatings and are speciality wire metal products, today wiro binding largest use in binding segment & printing industries, wire-o binding ring wire , double wire binding, or just wire binding and involves taking a preformed C shaped bookbinding wiro wire , placing the spine through the paper/book punching holes on the edge of your paper/book- document & books using a wiro closer machine to close the C shape into a round swirl binding element. Twin Loop wiro wire binding is considered to be one of the most elegant wiro bookbinding styles available on the Indian document binding market and is popular with real estate offices, architects, printing industries, book publishers, schools,college, engineers and marketing departments. However, wiro largest use in document binding industries, if you are considering using Twin Loop wiro binding machine in your office/shop there are a few things you might like to know

wiro ring different size & colour available, black & white regular use colour, another colour golden,silver, blue, green & red colour available against order, Wiro Binding Supplies,wiro manufacturing in India,wiro importer in India,



Wiro Ring ,

WIRE – O BINDING RING,

Wiro Binding Machine & Rings

Wiro Spool in Delhi
